Fujifilm Oasis Velocity 1.2T Open MRI Overview
Authorized Fujifilm MRI supplier. The Oasis Velocity is the highest field strength whole body open MRI from Fujifilm. It delivers a 1.2T vertical field magnet inside a truly open architecture. As a result, you capture excellent image quality without sacrificing patient comfort. The asymmetric table and gantry give every patient an unobstructed lateral view. Therefore the system serves claustrophobic, pediatric, elderly, and large patients with confidence.
This high-field open platform combines an advanced magnet design with Zenith RF technology and cutting-edge deep learning reconstruction. In addition, Synergy DLR and IP-RAPID enhanced reconstruction ship as standard. The 32" wide table lowers to 20" for easy access and supports up to 660 lbs. Because the imaging suites span Neuro, Orthopedic, Body, Breast, Vascular, and Cardiac work, one system covers a wide clinical caseload.
Need pricing? Get a quote with lead times within one business day.
Oasis Velocity Features and Performance
The Oasis Velocity balances open comfort with fully featured high-field imaging. Every subsystem works toward image quality, patient throughput, and reliable daily uptime.
The Oasis Velocity uses a vertical field superconducting magnet rated at 1.2T. Fujifilm tunes homogeneity to 0.3 ppm at a 35 cm DSV. In addition, computer-modeled passive shims and per-patient HOAST keep the field stable.
Innovative gradient amplifiers drive a 33 mT/m peak amplitude with slew rates up to 100 T/m/s. Therefore you can combine small fields of view with thin slices. SoftSound dampening and low noise sequences also reduce acoustic noise during scans.
The Zenith system combines multi-channel RF technology with exclusive vertical field coils. A solid state transmitter delivers 18 kW peak envelope power. Furthermore the digital receiver offers 16 channels and four coil connection points.
RAPID parallel imaging shortens scan times across the WIT and Zenith coil families. As a result, the standard imaging suites address Neuro, Orthopedic, Body, Breast, Vascular, and Cardiac exams. Synergy DLR reconstruction sharpens those images at no extra cost.
See how the Oasis Velocity compares with a generic open MRI baseline.
Because the magnet stays open on both sides, the Oasis Velocity keeps anxious and larger patients on schedule. At the same time, 1.2T field strength and powerful gradients support sub-millimeter slice thicknesses.
Full Specifications
All specifications below come from the Fujifilm Oasis Velocity specification data. Values reflect the standard configuration.
| Field strength | 1.2T |
| Magnet type | Vertical field superconducting |
| Homogeneity | 0.3 ppm @ 35 cm DSV |
| Cryogen | Helium only |
| Refill interval | Two years with approved maintenance |
| 5-Gauss fringe | 4.2 m horizontal, 3.3 m vertical |
| Peak amplitude | 33 mT/m |
| Maximum slew rate | 100 T/m/s |
| RF transmitter | Solid state, 18 kW peak |
| Receiver channels | 16 |
| Coil connection points | 4 |
| Acoustic control | SoftSound noise reduction |
| Patient aperture | 44 cm |
| Weight limit | 660 lbs (300 kg) |
| Table width | 83 cm |
| Table length | 252 cm |
| Vertical range | 50 to 89 cm |
| Lateral range | 10 cm right to left |
| CPU | Xeon 3.5 GHz, dual core |
| Memory | 16 GB RAM |
| Monitor | 24 in LCD, 1920 × 1200 |
| Disk storage | 500 GB |
| Archive | DVD 4.7 GB |
| Network | DICOM 3.0 compliant |
| AC power | 3-phase 480 V, 60 Hz |
| Capacity | 75 kVA |
| Scan room size | 23'8" × 16'6" |
| Min ceiling height | 8'11" |
| Gantry weight | 34,100 lbs |
| Scan room temp | 20 to 24°C |
Clinical Applications
The standard imaging suites equip the Oasis Velocity for a wide clinical caseload. Each suite uses dedicated sequences, enhancements, and post-processing tools.
AutoPose plans brain slices automatically. In addition, FLAIR, STIR, and diffusion sequences support detailed neuro studies.
RAPID shoulder, wrist, and foot or ankle coils target joints. Therefore high-resolution musculoskeletal exams stay fast and comfortable.
Respiratory and diaphragm navigation gating reduce motion. As a result, abdominal and pelvic studies stay sharp on open geometry.
The RAPID breast coil supports dedicated breast protocols. Furthermore dynamic analysis tools assist lesion evaluation.
FLUTE, TRAQ, and phase contrast methods capture flow. Non-contrast VASC sequences also help patients with renal insufficiency.
Cardiac gating with arrhythmia rejection times each acquisition. Because phase-cycled fat suppression is built in, cardiac contrast stays clean.
Patient-Centric Imaging Workflow
The Oasis Velocity puts the patient and the operator at the center of every scan. From registration through archiving, ORIGIN software keeps the pathway simple.
The asymmetric table and gantry give an unobstructed lateral view. The 32" wide table lowers to 20" for simple transfers. In addition, patient lighting and two-way intercom keep each person reassured.
ORIGIN organizes a protocol library by anatomical group. Therefore technologists move quickly from registration to exam. Rapid registration mode and HIS or RIS import also cut keystrokes.
I-Scan enables real-time imaging plane selection and MRI Fluoro updates. Class II laser positioning centers the patient to iso-center with plus or minus 1 mm accuracy. As a result, setup stays precise and repeatable.
Built-in tools include MIP, MPR, vascular volume rendering, and tensor analysis. Furthermore diffusion, perfusion, and spectroscopy analysis support advanced reads. Synergy DLR reconstruction sharpens the final images.
Sentinel delivers remote system and cryogen monitoring. Remote desktop and diagnostics help resolve issues quickly. Because of this, downtime stays low and service stays proactive.
Connectivity, Service, and Compliance
The Oasis Velocity integrates with hospital networks and includes proactive Fujifilm service. Review the standards and support details below.
ORIGIN software is DICOM 3.0 compliant. It supports Print, Query and Retrieve, Storage, Storage Commitment, Modality Worklist, and Modality Performed Procedure Step. Therefore the system fits standard PACS and RIS environments.
Fujifilm includes a 99% MRI uptime guarantee with the warranty and full service contract. In addition, periodic software and application training updates ship with ownership. As a result, lifetime cost stays lower.
The magnet uses helium only cryogen with a two-year refill interval under approved maintenance. Siting needs a 3-phase 480 V, 75 kVA supply and an RF-shielded scan room. Because the footprint is compact, replacement installs stay practical.
Medical Outfitters Inc. operates under an ISO 13485:2016 certified quality management system. We supply, document, and support the Oasis Velocity to that standard from Miami, Florida. Therefore you receive verified configuration and full traceability.
Request a Quote
Tell us your room size, power, and clinical mix. Our team will scope an Oasis Velocity configuration and siting plan for your facility.
Installation Planning
We coordinate shielding, power, and delivery for new or replacement rooms. As a result, your 1.2T open MRI install stays on schedule.
Frequently Asked Questions
Common questions about the Fujifilm Oasis Velocity 1.2T open MRI are answered below.
It offers 1.2T. Because of this, it is the highest field strength whole body open MRI from Fujifilm, so image quality stays high in an open form.
Yes. The asymmetric table and gantry give an unobstructed lateral view. Therefore anxious, pediatric, and elderly patients tolerate scans more easily.
The table supports up to 660 lbs (300 kg). In addition, it lowers to 20 inches for easy access, so larger patients can be scanned comfortably.
Yes. Synergy DLR and IP-RAPID enhanced image reconstruction ship as standard. As a result, you gain deep learning image quality without an extra purchase.
The Zenith system uses WIT and RAPID coil families. For example, RAPID shoulder, extremity, wrist, foot or ankle, and breast coils support targeted exams.
SoftSound technology dampens mechanical gradient noise. In addition, low noise sequences reduce sound, so the scan environment stays quieter.
It needs a 3-phase 480 V, 75 kVA supply and an RF-shielded scan room. A typical scan room measures 23 feet 8 inches by 16 feet 6 inches.
You can buy it from Medical Outfitters Inc., an ISO 13485:2016 certified supplier in Miami, Florida. Call (305) 885-4045 for pricing and siting support.
