Fujifilm Sonosite Edge II: Rugged Portable Ultrasound System
Authorized Fujifilm Sonosite ultrasound supplier. The Fujifilm Sonosite Edge II is a rugged, reliable, and responsive ultrasound system that can be used on or off an optional stand. Industry-first DirectClear Technology and Armored Cable Technology deliver clear ultrasound diagnostics that hold up in demanding environments, while a simplified interface keeps it easy for staff to operate. With 15 compatible transducers and scan depths from 6 to 35 centimeters, the Edge II handles a wide range of exams from a single durable platform.
Core technology: patent-pending DirectClear Technology embeds a more efficient material and a reflective layer into the transducer for improved penetration, contrast, and detail resolution. Armored Cable Technology wraps transducer cables in an embedded metal jacket so they keep performing even when twisted or stepped on. A 12.1-inch wide-angle LCD with a chemically etched glass layer stays clear from almost any angle, and a low-profile sealed keypad supports infection control. With SonoHD2 imaging, ColorHD, and Steep Needle Profiling, this Sonosite ultrasound system delivers clarity and confidence for musculoskeletal, nerve, vascular, and cardiac exams.
Need pricing? Get a quote with lead times and volume discounts within one business day.
DirectClear Imaging, Armored Cables & Durable Design
Three core strengths separate the Sonosite Edge II from a conventional ultrasound system: DirectClear transducer imaging, Armored Cable durability, and a rugged, easy-to-clean design. Each was engineered to deliver clarity and confidence in the toughest settings. Full technical detail is in the expandable sections below.
DirectClear Technology: A patent-pending process embeds a more efficient material into the transducer to generate more acoustic signal, with a reflective layer that reduces signal loss for improved penetration and contrast resolution
Sharpened Detail Resolution: An added acoustic matching layer increases the ability to resolve small structures and aids diagnostic confidence
Elevated Color Sensitivity: A dualflex thin-lens design and image optimization increase penetration, clarity, and color sensitivity for better visualization of nerves and vessels
SonoHD2 Imaging: Reduces speckle noise and artifacts while preserving and sharpening tissue information
ColorHD Technology: Improves color performance, sensitivity, and frame rates for more diagnostic information
Steep Needle Profiling: Enhances needle visibility for procedural guidance in nerve, musculoskeletal, and vascular work
Armored Cable Technology: An embedded metal jacket protects transducers from being rolled over, stepped on, or twisted, safeguarding electrical connections to maintain image quality over the life of the transducer
Wide-Angle Glass Display: A 12.1-inch full-bleed LCD with an anti-reflection etched glass layer needs minimal adjustment and stays clear at 85 degree viewing angles
Low-Profile Sealed Keypad: Snap-dome keys give tactile feedback and the keypad is sealed completely to the edge to inhibit liquid ingress for maximum infection control
SonoADAPT Tissue Optimization: Automatically tunes imaging parameters so clinicians get crisp images with few manual adjustments
DICOM Connectivity: DICOM image management lets the team print, store, and share exam results, including direct connection to a PC workstation
Drop-Tested Durability: The Edge II is drop-tested at 3 feet and cold starts in under 25 seconds
How the Sonosite Edge II compares against a conventional ultrasound system:
The Sonosite Edge II was engineered for clear ultrasound diagnostics in critical moments. DirectClear Technology elevates transducer performance for improved penetration and detail, while a thin-lens dualflex design lifts color sensitivity so clinicians can better visualize nerves and vessels for procedural guidance or flow analysis. Combined with the durable armored cables and an easy-to-clean sealed keypad, this Sonosite ultrasound system stays true to the design pillars of durability, reliability, and ease of use.
Full Technical Specifications
Complete reference data for capital procurement, RFP submissions, and biomedical engineering evaluation. This specification set is required by emergency, critical care, and imaging leads comparing rugged portable ultrasound system options. Expand each category.
| Imaging Modes | 2D, Tissue Harmonic Imaging, and M-Mode |
| Doppler Modes | Velocity Color Doppler, Color Power Doppler, PW, PW Tissue Doppler, and CW |
| DirectClear Technology | A patent-pending transducer process adds a more efficient material and a reflective layer for improved penetration and contrast resolution |
| SonoHD2 and ColorHD | Speckle noise reduction with elevated color performance and sensitivity for clearer nerves and vessels |
| Steep Needle Profiling | Enhances needle visibility for procedural guidance in nerve, MSK, and vascular work |
| Dynamic Range | All-digital broadband, up to 165 dB, with 256 shades of gray on the ultrasound screen |
| Compatible Transducers | Accepts 15 ultrasound transducers that switch from one to another in seconds through several ports |
| Ultrasound Transducer Types | Linear probe, curved array, phased array transducer, and multiplane TEE designs cover many ultrasound transducer types |
| Scan Depths | 6 to 35 centimeters across the transducer range for superficial to deep imaging |
| DirectClear & Armored Cable | DirectClear on the rC60xi and rP19x, with optional Armored Cable on the rC60xi, rP19x, L38xi, and L52x |
| Needle Guides | Needle guides and kits are available, including a transverse needle guide |
| System Weight | 9.21 lbs or 4.18 kg with the battery installed |
| Dimensions | 12.8 by 12.1 by 2.5 inches |
| Display | 12.1 inch diagonal LCD with a chemically etched anti-reflection glass layer |
| Viewing Angles | 85 degrees up, down, left, and right |
| Architecture | All-digital broadband, up to 165 dB, with 256 shades of gray |
| Durability | Drop-tested at 3 feet and cold starts in under 25 seconds |
| Musculoskeletal & Nerve | MSK, nerve, and small parts imaging with Steep Needle Profiling for procedural guidance |
| Vascular | Arterial, venous, and vascular access with elevated color sensitivity for vessels |
| Cardiology | Adult and pediatric cardiology, including multiplane transesophageal TEE imaging |
| Abdominal & OB/Gyn | Abdominal, OB, Gyn, and fertility exams with built-in measurement calculations |
| Breast & Superficial | Breast, superficial, ophthalmic, and orbital exams |
| Lung & Neurology | Lung imaging, neonatal head, and transcranial Doppler |
| DICOM Image Management | Print and store exam results through DICOM image management |
| PC Workstation | Direct connection to a PC workstation lets the whole team view exam results, even outside the room |
| HIPAA Compliance | A comprehensive HIPAA tool set keeps image sharing secure |
| Remappable Controls | Softkeys plus programmable A and B keys give quick access to frequently used functions like gain control |
| Image Acquisition | Dedicated review, report, clip store, and save keys, with AutoGain and exam keys |
| Cold Start & Battery | Cold starts in under 25 seconds with a rechargeable battery for extended use |
Clinical Applications
Built for clarity and confidence in critical moments, the Sonosite Edge II pairs DirectClear imaging with armored-cable durability across musculoskeletal, vascular, cardiac, and procedural-guidance exams.
DirectClear imaging and Steep Needle Profiling sharpen small structures for MSK, nerve, and small-parts exams, with linear probe options tuned for superficial anatomy.
Elevated color sensitivity clarifies arterial and venous flow, while needle guides and Steep Needle Profiling support confident vascular access and biopsies.
A phased array transducer handles adult and pediatric cardiology and abdominal exams, and a multiplane TEE option provides a full field of view of the heart.
Armored Cable Technology and a case drop-tested at 3 feet keep the Edge II working where standard cables get twisted, rolled over, or stepped on.
A low-profile keypad sealed completely to the edge inhibits liquid ingress, making the Edge II easy to clean between exams in high-traffic care areas.
Dedicated OB, Gyn, fertility, and breast exams are supported by a range of ultrasound transducer types with built-in measurement calculations.
Durability, Clarity & Ease of Use
A rugged ultrasound system engineered for clear diagnostics in critical moments. DirectClear imaging, Armored Cable durability, a clear anti-reflection display, and an easy-to-clean sealed keypad keep the Sonosite Edge II dependable and simple to operate. Expanded workflow details are in the expandable sections below.
DirectClear Technology is a patent-pending process that elevates transducer performance. A more efficient material generates more acoustic signal, a reflective layer reduces signal loss for improved penetration and contrast, and an added matching layer sharpens detail resolution. A thin-lens dualflex design lifts color sensitivity so clinicians can better visualize nerves and vessels.
Transducer cables get rolled over, stepped on, and twisted in everyday use. Armored Cable Technology wraps the cable in an embedded metal jacket that safeguards the electrical connections inside, helping maintain image quality over the life of the transducer. It is available on the rC60xi, rP19x, L38xi, and L52x.
A 12.1-inch wide-angle, full-bleed LCD with an anti-reflection etched glass layer needs minimal adjustment and stays clear at 85 degree viewing angles. Low-profile keys with snap-dome technology give tactile feedback, and the keypad is sealed completely to the edge to inhibit liquid ingress for maximum infection control.
DICOM image management lets the team print, store, and share exam results, with direct connection to a PC workstation so colleagues can view results outside the room. Softkeys and programmable A and B keys speed access to frequently used functions, and the system cold starts in under 25 seconds with a rechargeable battery for extended use.
Quality, Durability & Support
Manufactured by FUJIFILM Sonosite, Inc., the pioneer of point of care ultrasound, the Edge II is engineered around the design pillars of durability, reliability, and ease of use. Industry-first DirectClear and Armored Cable Technology, a drop-tested chassis, and a comprehensive HIPAA tool set back its clinical reliability. Medical Outfitters is an ISO 13485:2016 certified supplier of ultrasound and medical imaging equipment, meaning every Sonosite Edge II ships through a documented, audited quality management system. Full compliance documentation is available in the expandable sections below.
Manufacturer: FUJIFILM Sonosite, Inc., a pioneer of point of care ultrasound.
Design Pillars: The Edge II is built around durability, reliability, and ease of use.
ISO 13485: Medical Outfitters Inc. is independently ISO 13485:2016 certified as an ultrasound and medical imaging equipment supplier.
Durability: Drop-tested at 3 feet with Armored Cable Technology protecting the transducers.
Infection Control: A low-profile keypad sealed completely to the edge inhibits liquid ingress for easy cleaning.
HIPAA Compliance: A comprehensive HIPAA tool set keeps image sharing secure.
Installation Support: Nationwide delivery and configuration of the Sonosite Edge II.
Transducer Options: Guidance on selecting from 15 transducers and available needle guides.
Service: Medical Outfitters supports the purchase, setup, and maintenance of the system throughout its life.
Transducer & Configuration Review
Provide your clinical specialties and the ultrasound transducer types you need, from linear probe to phased array transducer. Our specialists confirm the right Sonosite Edge II configuration before purchase, then coordinate delivery and training.
Capital Equipment & RFP Support
Sonosite Edge II pricing, transducer options, and logistics coordination, including new and refurbished ultrasound machine for sale options. We support MSK, vascular, cardiac, and emergency buyers comparing rugged ultrasound system options. Contact us for a quote.
Frequently Asked Questions
Quick answers to the most common purchase and technical questions about the Fujifilm Sonosite Edge II ultrasound system. Tap any question to expand.
The Fujifilm Sonosite Edge II is a rugged portable ultrasound system that can be used on or off an optional stand. It features industry-first DirectClear Technology and Armored Cable Technology, a 12.1-inch wide-angle LCD with chemically etched glass, a sealed low-profile keypad, and 15 compatible transducers. With SonoHD2, ColorHD, and Steep Needle Profiling, it delivers clear diagnostics for musculoskeletal, nerve, vascular, cardiac, abdominal, and OB/Gyn exams.
The price depends on the transducers and configuration you select. Medical Outfitters offers new and refurbished ultrasound machine for sale options and returns a quote within one business day. Call (305) 885-4045 or request online to check current Sonosite Edge II availability.
DirectClear Technology is a patent-pending process that elevates transducer performance. A more efficient material embedded in the transducer generates more acoustic signal, a reflective layer reduces signal loss for improved penetration and contrast, and an added matching layer sharpens detail resolution so small structures are easier to resolve.
Armored Cable Technology wraps transducer cables in an embedded metal jacket that protects them from being rolled over, stepped on, or twisted. By safeguarding the electrical connections inside, armored cables help maintain image quality over the life of the transducer, which is especially valuable in busy or nontraditional imaging environments.
The Sonosite Edge II accepts 15 transducers across many ultrasound transducer types, including the linear probe, curved array, phased array transducer, and multiplane TEE designs, with scan depths from 6 to 35 centimeters. DirectClear is available on the rC60xi and rP19x, optional Armored Cable on several models, and needle guides and kits are available.
The Sonosite Edge II is built rugged, reliable, and responsive. It is drop-tested at 3 feet, the low-profile keypad is sealed completely to the edge to inhibit liquid ingress for infection control, and Armored Cable Technology protects the transducers. It also cold starts in under 25 seconds so staff can begin critical exams without delay.
The Sonosite Edge II uses a 12.1-inch wide-angle LCD ultrasound screen with a chemically etched anti-reflection glass layer. It stays clear at 85 degree viewing angles with minimal adjustment, so the team can read the ultrasound screen from almost any position during an exam.
Through Medical Outfitters Inc., ISO 13485:2016 certified, Miami, FL. New and refurbished Sonosite Edge II units with nationwide delivery and support. Call (305) 885-4045 or request a quote online to check current availability.
